| 1 |
Material Grade |
Specify material designation, chemical composition, mechanical properties, delivery condition, and applicable product form. |
Use the exact grade and temper, such as annealed, normalized, cold-worked, or solution-treated. |
Applicable ASTM, EN, ISO, JIS, or equivalent material specification; require a material test certificate. |
Confirm that the quoted grade is technically equivalent, not merely similar in trade name. Review chemistry, yield strength, tensile strength, and elongation. |
| 2 |
Material Thickness |
Define nominal thickness, allowable variation, measurement location, and whether coating or plating is included. |
For general sheet-metal work, a practical starting point is nominal thickness ±0.05 to ±0.15 mm, subject to material and process capability. |
Product-specific material standard and agreed inspection plan; measure with a calibrated micrometer or thickness gauge. |
Do not compare quotations using nominal thickness alone. Confirm minimum acceptable thickness after forming and finishing. |
| 3 |
Dimensional Tolerances |
Identify critical dimensions, datum references, geometric tolerances, and non-critical dimensions. |
Typical formed-part linear tolerances may range from ±0.10 to ±0.50 mm, depending on size, material, tooling, and process. |
ISO 2768 for general tolerances where applicable; ISO 1101 for geometrical tolerancing and GD&T practices. |
Use a controlled drawing revision and clearly mark CTQ dimensions. Avoid applying unnecessarily tight tolerances to every feature. |
| 4 |
Bend Radius and Formability |
Specify inside bend radius, bend direction relative to rolling direction, number of forming operations, and allowable cracking or wrinkling. |
A minimum inside radius of approximately 1.0t to 2.0t is common for many ductile sheet-metal applications, but high-strength materials may require more. |
Material forming-limit data, bend-test requirements, and supplier process validation. |
Request a feasibility review before tooling. Verify that the selected grade can meet the radius without splits, springback, or excessive thinning. |
| 5 |
Springback Control |
Define acceptable angular deviation, compensation method, measurement condition, and stabilization time after forming. |
A practical target for many precision bends is within ±0.5° to ±1.0°, subject to geometry and material strength. |
Drawing-specific angular tolerance; calibrated angle gauge, CMM, or optical measurement system. |
Check first-off parts and production capability. Higher-strength materials generally require stronger springback compensation. |
| 6 |
Surface Finish |
Specify surface roughness, visible-face requirements, tool marks, scratches, dents, discoloration, and allowable surface defects. |
For machined or post-formed areas, Ra 1.6 to 3.2 µm is commonly achievable; formed surfaces depend on tooling and incoming material. |
ISO 21920 for surface texture documentation; visual comparator or calibrated roughness tester where required. |
Define cosmetic zones separately from functional zones and approve a physical reference sample for international production. |
| 7 |
Flatness, Twist, and Distortion |
Define flatness method, datum plane, maximum gap, twist limit, and whether measurements are taken free-state or clamped. |
A common project-specific target is 0.5 to 2.0 mm maximum deviation per 1,000 mm, depending on part size and function. |
Drawing-defined geometric tolerance; surface plate, height gauge, straightedge, or CMM inspection. |
State the inspection condition clearly. Large thin parts may require support points or a defined fixture to obtain repeatable results. |
| 8 |
Mechanical Performance |
Specify tensile strength, yield strength, elongation, hardness, fatigue expectation, and any post-forming heat-treatment condition. |
Use grade-specific values from the governing material standard; do not substitute generic strength ranges. |
Relevant ASTM, EN, ISO, or JIS mechanical-test method; tensile testing is commonly performed under ISO 6892-1 or ASTM E8/E8M principles. |
Require test certificates or lot-based test reports when performance is safety-critical. Confirm sampling frequency and traceability. |
| 9 |
Corrosion and Environmental Resistance |
Define service temperature, humidity, salt exposure, chemical contact, coating system, coating thickness, and required service life. |
Coating thickness and corrosion-test duration must be project-specific; salt-spray hours should not be treated as a direct service-life guarantee. |
ISO 9227 or ASTM B117 for salt-spray testing where applicable; coating specification should define acceptance criteria. |
Confirm pretreatment, coating coverage inside bends, edge protection, and compatibility with the destination climate and regulations. |
| 10 |
Inspection, Sampling, and Documentation |
Define inspection level, sampling plan, approved measuring equipment, nonconformance process, packaging requirements, and document language. |
Use an agreed AQL or zero-defect requirement where appropriate; critical safety characteristics may require 100% inspection. |
ISO 2859-1 for attribute-based sampling; ISO 9001 quality-system controls; customer drawing and inspection plan. |
Agree on first-article approval, lot definition, calibration records, traceability, corrective-action timing, and export packaging before mass production. |
